Performance
| communication mode | USB (USB-KBW, USB-COM, HID-POS), RS232 (optional) |
| imaging sensor | CMOS, the global shutter |
| resolution ratio | 300 MP (640 * 480) |
| resolution | ≥5mil/0.127mm（PCS90%, CODE 39） |
| headlamp | Red LED fill light |
| Knowledge of deep reading | 10mm~350mm (different bar code range) |
| Decoding speed | 65CM /S |
| Reading mode | Continuous reading, induction reading, instruction control |
| prompting mode | suona, LED |
| angle of field | Horizontal 44° * vertical 33° diagonal 55 |
| Read the Angle | Test Conditions：CODE39,10mil/0.25mm,PCS90% |
| Rotate Roll: ± 360°, tilt Pitch: ± 65°, bias Skew: ± 60° | |
| Print contrast | ≥15% |
| ambient light | Dark environment, indoor natural light |
Mechanical / electrification properties
| Ontology weight | Approximately 425g (excluding wire material) |
| Appearance size | L 75mm * W 150mm * H 150mm |
| Wire length | 1.8 Meters |
| interface type | 10 The PIN crystal head |
| working voltage | DC 5V 1A |
| current | 115mA（Average W ork ）, 510mA(Max) |
work environment
| working temperature | -20℃ to 50℃ |
| storage temperature | -40℃ to 70℃ |
| Working humidity | 5% to 95% (no condensation) |
| Transport vibration test | 10H@125RPM |
